Mini 3W 5W uv laser marking machine for glass acrylic metal fabric printing

UV laser marking machine generates a laser beam with a certain wavelength through an UV laser with a laser wavelength of 355nm,and focuses the laser beam on the surface of the object to be marked through a galvanometer scanning system,so that the material changes physicall or chemically,thus forming a permanent mark.
LASER POWER:
3W
5W
  • Mini 3W 5W uv laser marking machine for  glass acrylic metal fabric printing
  • Mini 3W 5W uv laser marking machine for  glass acrylic metal fabric printing
  • Mini 3W 5W uv laser marking machine for  glass acrylic metal fabric printing
  • Mini 3W 5W uv laser marking machine for  glass acrylic metal fabric printing
  • Mini 3W 5W uv laser marking machine for  glass acrylic metal fabric printing
  • Description

  • Parameter


The machine takes 355nm light laser device as the light source. Ultraviolet laser marking machines have the advantage of limiting thermal stress that other laser machines do not.


1.This mini portable UV laser marking machine by Inngu is a versatile and efficient tool, ideal for a wide range of applications in various industries such as hotels, garment shops, and food and beverage factories.

2.With powerful 3W/5W UV laser technology, it can expertly engrave and mark a variety of materials including wood, plastic, and metal, making it perfect for personalized pet tags, business cards, and accessories.

3.The machine, provided with programmable features and a stand-alone configuration, comes with an easy-to-use control software, EZ CAD, for efficient and accurate marking of intricate designs and patterns.

4.Backed by a 2-year warranty and supported with professional after-sales services, this high-quality UV laser marking machine comes equipped with graphical formats like AI, BMP, and DXF, for enhanced customization and flexibility.

5.Additionally, this compact and energy-efficient model, with a working accuracy of 0.01mm and a lightweight of 70 kg, ensures smooth and precise operations, making it an indispensable asset for any home-based or professional user

UV laser can be used for ultra-fine marking and special material marking because of its small focused spot and smallinfluence of procesing heat.
High beam quality: UV laser beam has little damage to the material and can achieve clear and smooth marking effect. High precision: UV laser has shorter wavelength,which can achieve higher resolution and finer marking effect.
High speed: UV laser marking machine has high marking speed and is suitable for mass production.
Common material range: All kinds of plastics,glass,metal,silica gel,wood,bamboo,paper,fim,resin,ceramics,leather,acrylic and other common materials.
DIY: leaves,fruit surface,paper painting and other applications.
Application fields: widely used in precision instruments,medical equipment,electronic components,integrated circuits IC),gifts,food,medical packaging materials,flexible PCB marking and dicing;Micro-hole and blind hole machining of siicon wafer;LCD glass two-dimensional code

Model

LS

Laser source

5W(3W optional)

Wavelength

355nm

Marking area

100*100mm

Laser repetition frequency

20KHZ-150KHZ

Beam quality

M²≤1.2

Marking speed

7000-12000mm/s

Marking depth

0.01-1mm

Repetition Precision

0.013mm

Minimum Character

0.2 mm

Cooling Style

water cooling

Positioning Way

Red light

Control software

JCZ EZCAD marking software and UV laser marking machine software

Control board

JCZ

Supported Format

PLT, DXF, DST, AI, SDT, BMP, JPG, JPEG, GIF, TGA, PNG, TIF, TIFF,CAD, CDR, DWG and ETC

Operating Voltage

AC 110V/60HZ

Gross Power

≤500W

Supported Windows

Windows XP,7,8,10

Certificate

ISO, CE


1,The machine takes 355nm light laserdevice as the light source. Ultraviolet laser marking machines have the advantage of limiting thermal stress that other laser machines do not.
2, The heat affected area is very small, will not produce thermaleffects, will not produce material scorching problem.
3, The good quality and small focus spotlight could achieve the ultrafine marking with high speed and high efficiency.
4, Pre-installed high-precision practical multi-functional work surface, the table has a number of flexible screw holes,convenient installation of special fixture platform.
5. High efficiency of the photoelectric conversion and long servicelife.

Laser source

3W 5W 10W 15W

Wavelength

355nm

Marking area

100*100mm

Laser repetition frequency

20KHZ-150KHZ

Beam quality

M²≤1.2

Marking speed

7000-12000mm/s

Marking depth

0.01-1mm

Repetition Precision

0.013mm

Minimum Character

0.2 mm

Cooling Style

water cooling

Positioning Way

Red light

Control software

JCZ EZCAD marking software and UV laser marking machine software

Control board

JCZ

Supported Format

PLT, DXF, DST, AI, SDT, BMP, JPG, JPEG, GIF, TGA, PNG, TIF, TIFF,CAD, CDR, DWG and ETC

Operating Voltage

AC 110V/60HZ

Gross Power

≤500W

Supported Windows

Windows XP,7,8,10

Certificate

ISO, CE

Warranty

2 years
